Lab Magnetic Printer

Name: Lab Magnetic Printer
Brand: APPLE ELECTRONIKS
Price: 1700000 INR
Availability: InStock

Price 1700000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Lab Magnetic Printer Specification

Port Size
Standard specimen slot

Temperature
5C to 40C

Specimen Size
Up to 100 mm length

Test Range
0-10 kA/m (Kilampere per meter)

Humidity
Up to 80% RH non-condensing

Test Material
Ferromagnetic materials

Number of Specimens
Single specimen at a time

Type
Lab Magnetic Printer

Material
SS

Power
230 V AC, 50 Hz Volt (v)

Power Source
Electric

Dimension (L*W*H)
900 x 640 x 380 mm(LxWxH) Millimeter (mm)

Weight
100 Kg Kilograms (kg)

Usage
Industrial Use

Application
Magnetic particle examination of various samples

Display Type
Analog meter

Operating Mode
Manual

Accessories Included
Test lead, power cord, specimen holder

Finish
Epoxy powder coated

Calibration
Factory pre-calibrated

Safety Feature
Overload protection switch

Lab Magnetic Printer Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Week

Delivery Time
5-7 Week

Main Domestic Market
All India

About Lab Magnetic Printer

Lab Magnetic Printer

Known for its features like Frequency conversion adjusts speed, Adjustable magnetic force & its operation mode is running towards the left / right then automatic stop, this Lab Magnetic Printer is magnetic printing machine with printing area of 450-300mm. In addition to this, Lab Magnetic Printer is obtainable in the market with different sizes and shapes which suits the variegated needs of our esteemed patrons. Also, it comes with magnetically controlled roller for reproducible and accurate results with print paste.

Specifications

Printing area: 450 x 300mm ( Size 800x500mm is also available on request)
Screen frame size: 720 x 480mm (950x650mm also available on request)
Magnetic stick: Dia. 8, 12, 16, 20, 25mm, 350mm in length.(Each machine equipped with 1 Dia. 20mm magnetic stick only)
Drive mode: Motor - gear box toothed belt - magnetic block
Operation mode: Running towards the left / right then automatic stop; to and fro.
Speed control: Frequency conversion adjusts speed, digital display, 0 ~ 7 MPM
Magnetic Control: Adjustable magnetic force, 10 steps, digital display

Included Accessories

Magnetic Stick, Size Dia. 20 x 350mm, 1Pcs
Silk Screen, Size 650 x 480, 1 Pcs
Power 220 /110 V 50/60 Hz
Weight 100 Kg
Dimensions 900 x 640 x 380 mm(L x W x H)

Lab Magnetic Printer Manufacturer

Lab Magnetic Printer Supplier

Lab Magnetic Printer Exporter

Reliable Magnetic Particle Examination

Built for industrial environments, the Lab Magnetic Printer provides accurate magnetic particle examination for ferromagnetic samples. With a durable stainless steel construction and a pre-calibrated system, this device ensures seamless and reliable inspections. Its manual operation offers precision control, while the analog meter allows clear, real-time readings-making it indispensable in quality assurance and material testing processes.

Comprehensive Safety and User Features

Safety and usability are at the forefront of the Lab Magnetic Printer's design. The integrated overload protection switch safeguards against electrical surges, minimizing risk during operation. Accessories such as the test lead, power cord, and specimen holder are included for convenience. Finished in a long-lasting epoxy powder coat, the device is easy to clean and maintain, ensuring ongoing operational integrity.

FAQ's of Lab Magnetic Printer:

Q: How is the Lab Magnetic Printer used for magnetic particle examination?

A: To use the Lab Magnetic Printer, simply place a ferromagnetic specimen-up to 100 mm in length-into the standard slot, connect the provided test leads, and operate the device manually. The analog meter allows you to monitor the test range up to 10 kA/m. The unit is suitable for single-sample examination and is factory pre-calibrated for accurate results.

Q: What safety features are included with the Lab Magnetic Printer?

A: The printer is equipped with an overload protection switch, which automatically cuts off the power in case of excessive electrical load, thereby protecting both the device and the user during operation.

Q: When should calibration be performed on this printer?

A: The Lab Magnetic Printer arrives factory pre-calibrated, so it is ready for immediate use upon delivery. If you require recalibration or verification, it is advisable to consult the manufacturer's guidelines or calibrate at regular service intervals, based on the intensity of your usage.

Q: Where can the Lab Magnetic Printer be installed for optimal performance?

A: This device is best used in controlled industrial environments within the recommended temperature range of 5C to 40C and relative humidity up to 80% non-condensing. Its robust epoxy powder-coated finish ensures suitability for factory floors and quality control laboratories.

Q: What types of materials can be tested with this magnetic printer?

A: The Lab Magnetic Printer is specifically designed for magnetic particle inspection of ferromagnetic materials. Samples should be within 100 mm in length and single specimens can be evaluated at a time for optimal results.

Q: How does the overload protection feature benefit users?

A: The overload protection switch automatically disconnects the device from the power supply in the event of an electrical overload, protecting against damage and reducing the risk of operator injury, thus promoting safe and reliable testing operations.
