Price 6.95 आईएनआर/ Unit

मूल्य/उद्धरण प्राप्त करें

MOQ : 1 Unit

तापमान
Room temperature (approx. 232C)

नमूना आकार
Pre-cut 100 mm x 100 mm specimens

परीक्षण सामग्री
Nonwoven fabric, absorbent hygiene products

नमूनों की संख्या
Single specimen at a time

टेस्ट रेंज
0-999.9 seconds for strike through time

गैस का दबाव
Optional (if required for specific test protocols)

पोर्ट का आकार
Standard-direct test surface interface

नमी
Recommended 652% RH

टाइप करें

मटेरियल
SS

पावर
वाट (w)

पावर सोर्स
Electric

आयाम (एल* डब्ल्यू* एच)
मिलीमीटर (mm)

वज़न
किलोग्राम (kg)

उपयोग
Industrial Use

एप्लीकेशन
Testing of absorption and wet-repellency in feminine hygiene, diapers, medical textiles

Measurement Accuracy
0.1 seconds

Accessories Provided
Glass cylinder, weight, absorbent paper, cleaning accessories

Display
Large digital LCD

Control System
Microprocessor-based digital timer

Safety Features
Overload and short-circuit protection

Compliance Standards
Conforms to EDANA and INDA test methods

Strike Fluid Dose
Standard 5 ml or as per method

Minimum Order Quantity
1 Unit

आपूर्ति की क्षमता
प्रति सप्ताह

डिलीवरी का समय
हफ़्ता

मुख्य घरेलू बाज़ार
, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ऑल इंडिया

Liquid Strike Through Time & Wetback Tester

We provide Liquid Strike Through Time & Wet back Tester which is utilized to automatic measurement of liquid-strike-through time. Our given range is featured with automatic timing device & in this, two test can be operated in one instrument. Due to its qualities such as durability and optimal strength, this tester is widely appreciated in the market. Keeping in mind the specific needs of our patrons, we provide this Liquid Strike Through Time & Wet back Tester in several specifications.

Features

Two test can be operated in one instrument
Automatic timing device
Automatic placing the SBW, to exclude the interference of human factors

Specifications

Burette Volume: 50ml
Streaming speed of hopper: Flowed about 25ml during the time (3.5+/-0.25) s
The distance from specimens to hopper: 30mm
Organic Glass stand plate: 125mm x 125mm
Dimensions of specimens: 125mmx125mm
Accuracy of timer: 0.01s
Accuracy of Balance: 0.001g
Simulated baby weight: 4000+/-20g

Standards:

Test Standards conforms to :Liquid Strike-Through:EDANA WSP 80.10WSP 70.8ERT 154.0ERT151.3ISO 9073-8ISO9073-13GB/T24218.8GB/T24218.13For more test standard, please contact us

Test Standards conforms to :Coverstock Wetback:EDANA WSP 70.3WSP 70.7ERT 150.5ERT153.0ISO 9073-14GB/T24218.14

Power 220/110 V 50/60 Hz
Weight 45 Kg
Dimensions 500 x 350 x 800 mm(LxWxH)

Included Accessories

Hopper
Standard plate
Simulated baby weight

Optional/Required Accessories

Absorbent Pad (reference filter paper 100 mm x 100 mm)
Simulated urine (solution sodium chloride)
Burette

Product details

Grade	A1
Brand	Apple Electroniks
Color	WHITE
Display Type	Digital
Material	ms-ss
Power	230VAC
Country of Origin	Made in India

Liquid Strike Through Time & Wetback Tester Manufacturer

Liquid Strike Through Time & Wetback Tester Supplier

Liquid Strike Through Time & Wetback Tester Exporter

Reliable Precision and Compliance

This tester sets the benchmark in timing absorption speed and evaluating surface wetness for nonwoven hygiene materials. Its measurement accuracy supports reliable data collection, while strict adherence to EDANA and INDA standards ensures suitability for global industry requirements. Designed for single-specimen testing and incorporating safety features, it is both user-friendly and dependable in any lab or industrial environment.

Comprehensive Accessories and Easy Operation

The testing system comes with a glass cylinder, weight, absorbent paper, and cleaning tools, enabling straightforward testing from setup to cleaning. The intuitive microprocessor-based digital timer and large LCD display simplify the process, allowing efficient operation even for new users. The pre-cut specimen size and standard fluid dosing enhance consistency and reproducibility in results.

FAQ's of Liquid Strike Through Time & Wetback Tester:

Q: How does the Liquid Strike Through Time & Wetback Tester operate?

A: The tester uses a microprocessor-based digital timer to accurately measure the time required for a liquid to pass through a nonwoven fabric specimen (strike-through time) and the residual wetness (wetback). The process is initiated by applying a standard 5 ml liquid dose, with results displayed on a large LCD.

Q: What types of materials can be tested with this instrument?

A: The device is engineered for testing nonwoven fabric and absorbent hygiene products, such as feminine hygiene pads, diapers, and medical textiles, to assess their absorption capabilities and surface wetness performance.

Q: When should I use this tester in my product development or quality control process?

A: Use the tester during research and development, quality assurance, or batch acceptance phases to ensure your materials meet absorption and wet-repellency specifications as required by international standards like EDANA and INDA.

Q: Where is this tester typically used?

A: This equipment is widely used in industrial laboratories, quality control departments, and research facilities of manufacturers and exporters of hygiene products, particularly in India and global markets.

Q: What is involved in the testing process?

A: A pre-cut 100 mm x 100 mm specimen is placed in the tester. A calibrated glass cylinder delivers 5 ml of strike fluid onto the specimen under specified conditions. The digital timer measures the strike-through interval, and absorbent paper assesses surface wetness.

Q: How does this tester benefit my manufacturing or R&D department?

A: It delivers rapid, precise, and repeatable results, ensuring that hygiene materials conform to industry standards. The safety features, ease of use, and provided accessories streamline the testing workflow, supporting consistent product quality and regulatory compliance.

Q: What safety and compliance standards does the instrument meet?

A: The tester conforms to leading industry standards set by EDANA and INDA, and integrates overload and short-circuit protection for safe operation in industrial environments.
