Universal Testing Machine

Universal Testing Machine
Universal Testing Machine
Product Code : 04
Product Description

Universal testing machine offered by us is a best option to test the tensile stress and compressive strength of materials. All its name comes from the fact that, our offered Universal testing machine can perform many standard tensile and compression tests. Apart from this, provided machine is also known as a materials testing machine and can be used to test the tensile and compressive properties of materials. Featured with two columns options, this machine also available with single column types. Offered Universal testing machine has gained demand mostly in material testing laboratories.

Specifications:

  • PC operated and professional Textile Tensile Testing Software via high speed RS232
  • ARM 32 bit industrial SCM controls Panasonic AC servo driving system, and two quality ball-screws
  • 320 x 320 dip LED panel
  • Martial industrial load cells
  • Test space: Width 400mm x Height 800 mm
  • Pneumatic grips
  • Load measurement accuracy: +/-0.5% (2%-100%FS), +/-1% (1%-100%FS)
  • Resolution of load: 1/10000FS
  • Displacement resolution and accuracy: 0.001mm, +/-1% of indicated value.
  • Speed range and accuracy: 0.1 - 1000mm/min, +/-1% of set speed.
  • Built-in intelligent active force and displacement alarm system.
  • 32 bit precision motor controller.
  • Operating temperature range: 0 to 38 degrees C
  • Storage temperature range: -10 to 45 degrees C
  • Humidity range: 10% to 90% non-condensing, web bulb method.
  • Power must be free of spikes and surges exceeding 10% of the nominal voltage.
  • Power 220 /110 V 50/60 Hz
  • Weight 175 Kg
  • Dimensions 685 x 470 x 1650 mm (LxWxH)
